1L Capacity Combined Mixer Granulator Machine With Alloy Constructed
| MOQ: | 1 set |
| Price: | $27500-$37800 |
| Standard Packaging: | Wooden cases |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
Detail Information
Place of Origin
Guangdong,China
Brand Name
CFine
Certification
CE,ISO 9001
Model Number
CF-1L
Capacity:
1L
Mixing Main Motor:
3.75KW
Pressure Cylinder:
￠63
Speed (Front/Back)::
0-40/31r/m
Type Of Heating:
Electrical Heating
Type Of Cooling:
Forced Air Cooling
Extrusion Motor:
2.2kw
Rotor Type:
Double-leaf Type
Highlight:
1L Combined Mixer Granulator
,Combined Mixer Granulator Machine
Product Description
1L Capacity Combined Mixer Granulator Machine With Alloy Constructed
Custom 1L Low Price Consumption Combined Mixer-Granulator
All material-contacting components of this mixer—including the chamber, side plate, pressure hammer, and blade shaft—are constructed entirely from alloy, eliminating the need for spraying or electroplating. The equipment is suitable for stirring, dispersing, and blending metal powders as well as binder-based formulations under controlled temperatures. Once the mixture forms a mud-like mass, it is extruded and granulated after a set period before moving on to the next stage of processing.
Technical Specifications
| Model | CF-1L35Z | CF-5L60Z | CF-10L75Z | CF-15L80Z |
|---|---|---|---|---|
| Capacity | 1L | 5L | 10L | 15L |
| Main Motor | 3.75KW | 7.5KW | 15KW | 18.5KW |
| Pressure Cylinder | ￠63 | ￠100 | ￠160 | ￠160 |
| RPM (front/rear) | 0-40/31 r/min | |||
| Type of Cooling | Electric Heating | Ventilation cooling / Water-cooling | ||
| Gauge of the screw rod | 35MM | 60MM | 75MM | 80MM |
| Extrusion Motor | 2.2KW | 5.5KW | ||
| Grinding Motor | 0.75KW | |||
| Size | L1850*W1200*H2000mm | L2000*W1100*H2200mm | L2650*W1300*H2800mm | L2750*W1400*H2800mm |
| Weight | About 1200KG | About 2200KG | About 2800KG | About 3000KG |
| Power | 3∮ AC380V 50HZ | |||
Working Principle
The mixer's two rotors turn at different speeds, pulling material from the inlet and forcing it into the gap where it is squeezed and sheared. Afterward, the mixture hits the chamber's "W"-shaped ridge, splitting into two flows that move along the chamber walls and rotors before returning to the top. In the sealed chamber, the combination of pressure, heat, and shear produces thorough mixing and plasticization, helping the formula reach its best results.
Mixing System
The mixing chamber is "W" shaped and adopts an "M" shaped lower pressure cover to form a fully enclosed mixing space. The stirring blade features a prismatic spiral design without dead angles, ensuring material shearing and dispersion meet physical property requirements. The stirring blade is a hollow structure, and all material-contact components (mixing chamber, side plate, pressure hammer, stirring blade shaft) are made of full alloy material—eliminating the need for spraying or electroplating—providing excellent wear resistance, corrosion resistance, non-stick properties, and long service life.
Product Superiority
- The motor and electrical components adopt a fully sealed structure, providing waterproof and dustproof protection
- The oil outlet is equipped with a pressure gauge that automatically alarms when pressure is too high
- Oil storage tank monitoring system
- Programmable oil filling operation cycle with adjustable timing on the control panel
- Dust and odor-proof collection shield installed above the mixing tank with air outlet for factory dust collection system connection, effectively reducing operator exposure to dust and harmful gases
- Integrated thermal insulation system
After-sales Service
During normal use, non-consumable parts are guaranteed for one year. We provide on-site installation guidance and long-term technical support.
Note: Electrical components and motors are imported from Taiwan and foreign brands.
