400×400mm Flat Vulcanizing Machine 15Kw Industrial Rubber Vulcanization Equipment
| MOQ: | 1 set |
| Price: | $13900-$20600 |
| Standard Packaging: | Wooden cases |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
400×400mm Flat Vulcanizing Machine
,Flat Vulcanizing Machine 15Kw
,15Kw Rubber Vulcanization Equipment
This industrial vulcanizing machine features a PLC touch-screen controller with interactive HMI system, supporting precise parameter input for temperature, pressure, timing, and exhaust operations. Real-time workflow monitoring and fully automated processing ensure exceptional efficiency, intelligent operation, and simplified maintenance.
| Model | CF-300B | CF-400B | CF-500B | Customization Options |
|---|---|---|---|---|
| Capacity | 30T | 30T | 30T | Working pressure, working area, number of floors, and cooling/heating plates can be customized according to customer requirements |
| Working Area | 300mm × 300mm | 400mm × 400mm | 500mm × 500mm | |
| Number of Floors | Two floors | Two floors | Two floors | |
| Cooling and Heating Plate | One heating, One cooling | One heating, One cooling | One heating, One cooling | |
| Total Power | 11Kw | 15Kw | 20Kw | |
| Weight | 750Kg | 950Kg | 1200Kg |
Manufactured from imported high-temperature resistant steel with deep carbonization and hard chrome plating surface treatments. Features include rapid heat transfer, corrosion resistance, high hardness, and deformation resistance. Built-in heaters and temperature sensors provide high power output, fast heating, sensitive temperature measurement, and minimal temperature variance.
Constructed from aluminum material with anodized surface treatment for superior corrosion resistance and rapid heat conduction.
Four hardened, precisely positioned columns and hydraulic cylinders supported by a thick steel plate base. Self-lubricating bronze bearings ensure smooth, noiseless vertical movement. Heavy steel surrounds the top and rear for enhanced operator safety. Upper layer steel plates incorporate embedded thermocouples near the surface for accurate temperature monitoring.
Primarily used in rubber and plastic products manufacturing, polyolefins, PVC, films, coils, profiles production, polymer blending, pigments, masterbatches, and stabilizers industries. Essential for testing physical property changes and comparisons of raw materials after molding processes.
- Color dispersion analysis and material surface evaluation
- Transparency, glossiness, and defect detection (black spots, stains)
- Strength, plasticity, and hardness testing with additives
- Supplier raw material quality verification
- Comparative analysis of similar products
- Research and development for new product formulation
- Pre-production validation for manufacturing processes
- Detection of gel (fish eyes), black spots, and stains in raw materials
- Pressing and sample preparation of raw materials
- Comprehensive physical property testing
- Advanced material research and development
