Custom 300×300mm Rubber Vulcanizing Press Machine Automatic Control
| MOQ: | 1 set |
| Price: | $10200-$19500 |
| Standard Packaging: | Wooden cases |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
Detail Information
Place of Origin
Guangdong,China
Brand Name
CFine
Certification
CE,ISO 9001
Model Number
CF-300B
Material:
Imported Alloy
Capacity:
30-T
WorkingArea:
300mM*300mM
Number Of Floors:
2 Floors
Cooling And Heating Plate:
One For Heating And One For Cooling
Total Power:
11kW
Weight:
750kG
Custom:
Customer's Requirements
Highlight:
300x300mm Rubber Vulcanizing Press Machine
,Rubber Vulcanizing Press Automatic Control
,Custom Rubber Vulcanizing Press Machine
Product Description
Custom 300*300mm Rubber Vulcanizing Press Machine with Automatic Control
This custom 300*300mm plate vulcanizing machine features a PLC program with color touch panel and HMI operating system, enabling easy configuration of process parameters including temperature, pressure, cycle time, and exhaust counts. The system provides real-time vulcanization progress monitoring and automated program execution for intelligent, efficient operation with straightforward structural design.
Technical Specifications
| Model | CF-300B | CF-400B | CF-500B | Remarks |
|---|---|---|---|---|
| Capacity | 30T | 30T | 30T | Working pressure, working area, number of floors, and cooling/heating plates can be customized according to customer requirements |
| Working Area | 300mm * 300mm | 400mm * 400mm | 500mm * 500mm | |
| Number of Floors | Two floors | Two floors | Two floors | |
| Cooling and Heating Plate | One heating, One cooling | One heating, One cooling | One heating, One cooling | |
| Total Power | 11KW | 15KW | 20KW | |
| Weight | 750KG | 950KG | 1200KG |
Product Features
Heating Plate
Constructed from imported high-temperature resistant steel with deep carbonization and hard chrome plating surface treatments. Features fast heat transfer, corrosion resistance, high hardness, and no deformation. Built-in heaters and temperature sensors provide high power output, rapid heating, sensitive temperature measurement, and minimal temperature error range.
Cold Conduction Plate
Aluminum construction with anodized surface treatment for corrosion resistance and rapid heat conduction.
Guide Columns
Four hardened, precisely positioned columns and hydraulic cylinders supported by a thick steel plate base. Features self-lubricating bronze bearings for smooth, noiseless lifting and lowering. Heavy steel surrounds the top and rear for operator safety protection. Upper layer includes steel plate with inserted thermocouples near the surface.
Operating Principle
Raw materials are placed in the mold where rubber is shaped under rated pressure and temperature. After reaching the melting point over a specified period, the product achieves defined physical properties.
Applications
Primarily used in rubber and plastic products, polyolefins, PVC, films, coils, profiles production, polymer blending, pigments, masterbatches, and stabilizers. Designed to test physical property changes and comparisons of raw materials after molding, including color dispersion, light transmittance, surface glossiness, detection of black spots, strength, plasticity, and hardness with added auxiliary materials.
- Detection of gel (fish eyes), black spots, and stains in raw materials
- Pressing and sample preparation of raw materials
- Physical property testing
- Material research and development
Ideal for factory quality control of supplier raw materials, product comparisons, and research and development applications in academic and industrial settings. Provides valuable reference data prior to mass production.
