Two Floors Plate Rubber Vulcanizing Machine 300×300mm 11kw vulcanizing press

Two Floors Plate Rubber Vulcanizing Machine 300×300mm 11kw vulcanizing press

MOQ: 1 set
Price: $10200-$19500
Standard Packaging: Wooden cases
Payment Method: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Place of Origin
Guangdong,China
Brand Name
CFine
Certification
CE,ISO 9001
Model Number
CF-300B
Material:
Imported Alloy
Capacity:
30(T)
WorkingArea:
300Mm*300Mm
Number Of Floors:
2 Floors
Cooling And Heating Plate:
One For Heating And One For Cooling
Total Power:
11Kw
Weight:
750Kg
Custom:
According To The Customer's Request
Highlight:

Two Floor Rubber Vulcanizing Machine

,

Rubber Vulcanizing Machine 300×300mm

,

11kw Vulcanizing Press Machine

Product Description
Two Floors Plate Rubber Vulcanizing Machine 300×300mm 11kw Vulcanizing Press
Custom 300×300mm Plate Vulcanizing Machine for Rubber Products
Product Overview
This machine features a PLC program color touch screen controller and man-machine interface operation system. It allows setting parameters such as pressure, temperature, time, and exhaust times, with instant display and monitoring of the vulcanization process. All programs are automatically completed, making the machine intelligent, efficient, and structurally simple.
Technical Specifications
Model CF-300B CF-400B CF-500B Remarks
Capacity 30T 30T 30T Working pressure / working area / number of floors / cooling and heating plates can be customized according to customer requirements
Working Area 300mm×300mm 400mm×400mm 500mm×500mm
Number of Floors Two floors Two floors Two floors
Cooling and Heating Plate One for heating
One for cooling
One for heating
One for cooling
One for heating
One for cooling
Total Power 11kw 15kw 20kw
Weight 750kg 950kg 1200kg
Product Superiority
  • Heating Plate: Made of imported high-temperature resistant steel with deep carbonization and hard chrome plating surface treatment. Features fast heat transfer, corrosion resistance, high hardness, and no deformation. Built-in heater and temperature sensor provide high power, fast heating, sensitive uniform temperature measurement, and minimal temperature error range.
  • Cold Conduction Plate: Aluminum material with anodized surface for corrosion resistance and fast heat conduction.
  • Guide Columns: Four hardened and precisely positioned columns with hydraulic cylinders supported by thick steel plate base. Self-lubricating bronze bearings ensure smooth, noiseless lifting and lowering. Heavy steel surrounds the top and rear for operator safety protection. Upper layer features steel plate with inserted thermocouples near the surface.
Operating Principle
Raw materials are placed in the mold, where rubber is shaped under rated pressure and temperature. After reaching the melting point over a specified period, the product obtains specific physical properties.
Applications
Primarily used in rubber and plastic products, polyolefins, PVC, films, coils, profiles production, polymer blending, pigments, masterbatches, stabilizers, and related industries. Main purposes include testing physical property changes and comparisons of raw materials after molding, such as color dispersion, light transmittance, surface glossiness, detection of black spots, strength, plasticity, and hardness after adding auxiliary materials.
Ideal for factory inspection of supplier raw materials, comparison of similar products, and research and development in universities and corporate R&D departments. Serves as a reference for factories before mass production.
Typical Applications:
  • Detection of gel (fish eyes), black spots, and stains in raw materials
  • Pressing and sample preparation of raw materials
  • Physical property testing
  • Material research and development
