11kw Atmosphere Protection Granulator Machine With Oxygen Content Test Table
| MOQ: | 1 set |
| Price: | $27000-$30000 |
| Standard Packaging: | Wooden cases |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
Detail Information
Place of Origin
Guangdong,China
Brand Name
CFine
Certification
CE,ISO 9001
Model Number
CF-5L60Z
Each Batch Input:
20~25Kg
Screw Diameter:
60Mm
Length Duameter Ratio:
16:1
Main Motor:
11Kw
Material Cooling:
Wind Conveys Cooling
Size:
L4000*W1500*H1800Mm
Weight:
About 1600Kg
Power:
3∮ AC380V 50HZ
Each Batch Input:
20~25Kg
Screw Diameter:
60Mm
Length Duameter Ratio:
16:1
Main Motor:
11Kw
Material Cooling:
Wind Conveys Cooling
Size:
L4000*W1500*H1800Mm
Weight:
About 1600Kg
Power:
3∮ AC380V 50HZ
Highlight:
Atmosphere Protection Granulator Machine
,11kw Granulator Machine
Product Description
Atmosphere Protection Granulator Machine With Oxygen Content Test Table
CFine Custom CF-5L60Z Atmosphere Protection Granulator
This industrial granulator features forced double-wrist feeding technology that directly processes mixed metal powder agglomerate materials. This innovative design eliminates the need for additional crushing steps that can compromise material granulation quality while preventing contamination during the processing cycle.
Technical Specifications
| Model | CF-1L45Z | CF-3L45Z | CF-5L60Z |
|---|---|---|---|
| Mixer Combination | 1L | 3L | 5L |
| Screw Diameter | 45mm | 45mm | 60mm |
| Length Diameter Ratio | 16:1 | ||
| Main Motor | 7.5kw | 7.5kw | 11kw |
| Feed Motor | 0.75kw | 0.75kw | 1.5kw |
| Grinding Motor | 0.75kw | 0.75kw | 0.75kw |
| Material Cooling | Wind Conveys Cooling | ||
| Size | L3800*W1200*H1800mm | L3800*W1200*H1800mm | L4000*W1500*H1800mm |
| Weight | Approx. 1500kg | Approx. 1500kg | Approx. 1600kg |
| Power Supply | 3∮ AC380V 50HZ | ||
Key Features
- Integrated flow meter scale display for precise monitoring
- Built-in oxygen content test table for atmosphere control
- Detachable charging hopper design for easy rotor cleaning
- Four-sided inflatable protection on feeding barrel
Gearbox System
Engineered to ZBJ19009-88 technical specifications, the gearbox utilizes high-strength alloy steel gears and shaft components. Gear precision meets GB10095-88 Grade 6 standards with tooth surface hardness of HRC-60. An oversized thrust bearing at the output shaft end handles screw back thrust, while domestic high-quality bearings and oil seals ensure reliability. The system delivers high load capacity, stable transmission, low noise operation, and exceptional efficiency.
- Reduction Ratio: 10:1
- Hardened tooth surface ground gears for quiet operation and extended service life
- Oil-immersed lubrication system
Barrel and Screw Construction
- Material: 38CrMoALA alloy steel with 72-hour nitriding treatment and polished wear-resistant surface (specialized for metal powder)
- Nitriding depth: 0.6-0.8mm with hardness ratings of 780HV (screw) and 850HV (barrel)
- Screw diameter: Ø45mm
- Screw aspect ratio: 16:1
Electrical Control System
- Power supply: 3-AC380V, 50HZ
- Temperature control: 3-zone digital temperature controller
- Integrated electric control cabinet and host
- Premium components from Taiwan Shilin, Omron, and Tende
After-Sales Service & Support
Non-consumable parts are guaranteed for one year during normal operation. We provide comprehensive on-site installation guidance and long-term technical support to ensure optimal performance.
Electrical components and motors are imported from Taiwan and international brands.
