Twin Rotors Farrel Banbury Mixer Continuous Internal Mixer 110KW 110mm Pipe Diameter
| MOQ: | 1 set |
| Price: | $109800-$130300 |
| Standard Packaging: | Wooden cases |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
Detail Information
Place of Origin
Guangdong,China
Brand Name
CFine
Certification
CE,ISO 9001
Model Number
CF-110LXS
Nominal Pipe Diameter:
φ110MM
Rotor Max Speed:
500RPM
Main Motor Power:
110KW
Screw Diameter:
φ135MM
Screw Length To Diameter Ratio:
10
Screw Maximum Speed:
75RPM
Motor Power:
45KW
Output(PE+50%CACO3):
About 550KG/h
Highlight:
Twin Rotors Farrel Banbury Mixer
,Continuous Internal Mixer 110KW
,Farrel Banbury Mixer 110KW
Product Description
Twin Rotors Farrel Banbury Mixer Continuous Internal Mixer 110KW 110mm Pipe Diameter
Custom CF-110LXS High Quality Farrel Continuous Mixer
Product Overview
Engineered with twin rotors, this continuous internal mixer delivers high-performance mixing and compounding for polymer-based materials including rubber, plastics, and elastomers. Ideal for applications requiring uninterrupted production, uniform dispersion, and effective handling of high-filling systems. The equipment combines classical internal mixer functionality with extrusion technology, providing an end-to-end continuous process from material input to discharge.
Technical Specifications
| Model | CF-50LXS | CF-85LXS | CF-110LXS | CF-135LXS | CF-165LXS |
|---|---|---|---|---|---|
| Nominal pipe diameter | φ50MM | φ85MM | φ110MM | φ135MM | φ165MM |
| Rotor Max Speed | 700RPM | 500RPM | 500RPM | 500RPM | 500RPM |
| Main motor power | 37KW | 75KW | 110KW | 160KW | 315KW |
| Screw diameter | φ75MM | φ120MM | φ135MM | φ165MM | φ200MM |
| Screw length to diameter ratio | 14 | 12 | 10 | 10 | 10 |
| Screw maximum speed | 75RPM | 75RPM | 75RPM | 75RPM | 75RPM |
| Motor power | 11KW | 30KW | 45KW | 55KW | 132KW |
| Speed change | Change by frequency changer | ||||
| Output (PE+50%CACO3) | About 125 | About 250 | About 550 | About 1000 | About 2000 |
Product Advantages
- Feeding: Continuous feeding system
- Environment: No powder fluttering, maintains clean workshop conditions
- Dimension: Combined machine design with small footprint and low storey height requirements
- Automation: Easy integration with automatic weighing systems
- Product Quality: Continuous operation ensures consistent, high-quality output
- Energy Saving: Steady current consumption with no significant peaks during mixing process
Applications
Rubber compounds, carbon black masterbatch, calcium powder filling masterbatch, talc powder filling masterbatch, functional masterbatch, high concentration masterbatch, flame retardant masterbatch, cable materials, high filling materials, and various polymer compounding applications.
