10L Industrial Dispersion Kneader Machine Erosion Resistant For Mixing Kneading
| MOQ: | 1 set |
| Price: | $41200-$52800 |
| Standard Packaging: | Wooden cases |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
Detail Information
Place of Origin
Guangdong,China
Brand Name
CFine
Certification
CE,ISO 9001
Model Number
CF-10LKH
Capacity:
10~L
Main Motor:
15kW
Pressure Cylinder:
￠160
Speed (forward / Backward):
0-40/31R/m
Type Of Cooling:
Water-cooling
Size:
L1300*W1400*H2800mM
Weight:
About 3500kG
Power Supply:
3∮ AC380V 50HZ
Highlight:
Industrial Dispersion Kneader
,10L Dispersion Kneader
Product Description
10L Industrial Kneader Machine - Erosion Resistant For Mixing & Kneading
Custom 10L Type Kneader For Ceramic Mixing
Constructed with premium imported alloy materials, this internal mixer eliminates the need for traditional coating or plating processes while delivering exceptional strength and abrasion resistance. Engineered for precision blending, dispersion, and uniform mixing of ceramic powders, binders, and related formulations under controlled heat conditions, it effectively produces mud-consistency mixtures. The batch is discharged at scheduled intervals, ready for subsequent processing. Compact and versatile, it serves as an ideal tool for experimental studies, trial production, small-batch runs, and instructional applications in universities and research institutes.
Technical Specifications
| Model | CF-1LKH | CF-3LKH | CF-5LKH | CF-10LKH |
|---|---|---|---|---|
| Capacity | 1L | 3L | 5L | 10L |
| Main Motor | 4Kw | 7.5Kw | 11Kw | 15Kw |
| Pressure Cylinder | ￠63 | ￠80 | ￠100 | ￠160 |
| RPM (Front/Rear) | 0-40/31 R/M | |||
| Cooling Type | Water-cooling | |||
| Heating Type | Electrical Heating | |||
| Size | L1000*W800*H2150mm | L1150*W1300*H2400mm | L1200*W1350*H2400mm | L1300*W1400*H2800mm |
| Weight | About 930Kg | About 2080Kg | About 2530Kg | About 3500Kg |
| Power | 3∮ AC380V 50HZ | |||
Product Superiority
- Imported all-alloy materials eliminate the need for spraying or electroplating, providing exceptional resistance to erosion and corrosion including salt, acid, alkali, and hydrogen sulfide corrosion, with high precision and superior finish
- Hydraulic system automatically opens the mixing chamber with easy rotor disassembly, overcoming traditional mixer limitations in cleaning, color changing, and maintenance
- All material contact surfaces feature mirror-polished finish to prevent material adhesion and simplify cleaning, effectively controlling machine contamination
Technical Advantages
- Advanced anti-leakage powder device utilizes mechanical shaft seal tightening technology with self-lubricating seal rings that maintain compression during mixing, reducing system wear and eliminating noise from leakage issues
- Through-type heating system provides faster heating and more uniform temperature distribution with 50% higher efficiency compared to traditional heating plates, controlled by PLC program system
- Complex tube-belt design in mixing chamber ensures excellent heat exchange and precise temperature control, with water-cooled rotor preventing material adhesion and enabling uniform dispersion
After-Sales Service
During normal operation, non-consumable parts are guaranteed for one year free of charge. We provide on-site installation guidance and long-term technical support to ensure optimal performance.
